uni NTB

The Nano Transfer Belt.

Size matters! The smallest pitch modular belt in our product range. Great for conveying small bakery products and/or delicate goods smoothly.

Product features:

• Ideal for tight transfers
• Designed for use with knife-edge transfers
• Hinge remains closed around knife-edge
• Clever sprocket design provides tracking
• Closed surface for food applications

uni M-TTB

Open area, cleanable small pitch belt. A perfect solution for food processing (cooling, freezing, drying or proofing applications).

Product features:

• High strength robust design
• Smooth operation over small transfers
• Improved non-stick characteristics and reduced friction with standard POM-D and PP materials.
• Efficient product transfer and less product contact area with the curved surface design.

uni M-QNB

Universal small pitch belt for food and industrial applications.

Product features:

• Rounded bottom surface ensures smooth running over knife-edge transfers
• Closed top surface and hinges
• High load capacity
• Unique lock-pin locking system for easy maintenance

uni M-OWL

Ideal for transporting and processing applications needing small in-line transfers. Good option to replace old (and often dirty) steel wire mesh belts.

Product features:

• Very open design
• Low contact surface area
• Smooth running over transfers

uni M-SNB

Open area 0.5 inch pitch belt system suitable for food and non-food applications needing small transfer gaps.

Product features:

• Small pitch with open surfaces
• Knife-edge transfers possible
• Choice of surface profiles

AVE 9123

Modular belt for container handling. Metric width standards.

Product features:

• 8.7 mm thickness
• Profiled belt base for smooth in-line product transfers over knife end profiles
• Active sideways Transfer system and tracking guides

Nomenclature :

• C = Closed Top
• AT = Active Transfer System
• BP = Backline Pressure Reduction Rollers
• GF = Grip Face

uni Light

Universal small pitch belt for industrial and packaged products transportation.

Product features:

• Open and closed surfaces
• Closed hinge construction
• Versatile belt available in many variations
• Full range of accessories

uni SNB

A best seller!

Open 1 inch pitch belt with a very cleanable design for a variety of applications mainly in food and beverage.

Product features:

• High strength and easy to use LockPin system
• Reduced dirt build up thanks to different self-cleaning surfaces
• Less friction and product contact
• Available in a variety of open ratios
• Customisable: rubbertop, tabs, flights

uni S-MPB

Strong hygienic 1 inch pitch belt suitable for raw food processing applications.

Is available in the unique uni Single Link^® format.

Product features:

• Easy to clean hygienic belt
• Open hinge designed for pressure wash cleaning
• Impact-resistance bar on underside
• Available with unique 20 inch wide flight

uni CNB

Very easy to clean 1 inch pitch belt for conveyance of light duty products in various food applications.

Product features:

• Unique hinge and sprocket designs increase the cleanability
• Available with different openings to optimise drainage and airflow

uni QNB

Standard 1 inch pitch closed belt for reliable conveying in a multitude of industries.

Developed with focus on optimising strength, rigidity and wear life.

Product features:

• Unique sprocket engagement reducing pulsation
• Strong bi-directional belt for long conveyors
• Chamfered edges provide easy side transfers

uni JCB

An industry favourite!

Standard belt for Corrugated Board Industry stack handling systems.

Product features:

• Safewalk Y profile top surface
• High visibility belt edges
• Profiled base for smooth product transfers
• High working load capacity

uni LPB

Light duty 1 inch pitch people mover belt, ensuring that workers are transported at the same speed as the product being assembled.

Moving people safely with ‘gentle grip’ belt profile.

Features a safe walk surface, high tensile working load capacity and rigidity and is low friction and wear-resistant.

Product features:

• High tensile load capacity
• Long conveyors possible
• Safe walk surface
• Anti-static material options

AVE 9253

Modular belt for container handling. Metric width standards.

Product features:

• 8.7 mm thickness
• Flat smooth top surface for container stability
• Active sideways Transfer system and tracking guides

Nomenclature :

• C = Closed Top
• AT = Active Transfer System
• R = Rib Top
• TC = Transfer Comb
• V = Vented 33%
• GF = Grip Face
• E = E Product Supports

AVE 9252

Open surface modular belt. Metric width standards.

Product features:

• Flat OPEN top surface for container stability
• 8.7 mm standard thickness
• Wear resistant edge profile

Nomenclature :

• O = Open Flat Top

AVE 9255

Modular belt for container handling. Metric width standards.

Product features:

• Heavy duty 12.7 mm thickness
• Flat smooth top surface for container stability
• Active sideways Transfer system and tracking guides

Nomenclature :

• C = Closed Top
• AT = Active Transfer System
• BP = Backline Pressure Reduction Rollers
• GF = Grip Face
• MC = Modular Chain Belt
• MC P1 = Modular Chain Belt P1 Guides
• MC P2 = Modular Chain Belt P2 Guides
• MV = Modular Ventilated Chain Belt
• MV P1 = Modular Ventilated Chain Belt P1
• MV P2 = Modular Ventilated Chain Belt P2

AVE 9100

Modular belt for container handling. Imperial width standards.

Product features:

• 12.7mm thickness
• Flat smooth top surface for container stability
• Active sideways Transfer system

Nomenclature :

• C = Closed Top
• AT = Active Transfer System
• R = Rib Top
• TC = Transfer Comb
• V = Vented 21%
• P = Perforated 8%

uni OWL

Very open 1.1 inch pitch belt with a patented non-stick belt surface created for applications requiring large open areas and little product contact.

Product features:

• Heat and wear-resistant
• Operating temperature of 180 °C with special material
• Can resist peak temperature up to 230 °C with special material
• Minimal contact surface

uni Light EP

1.5 inch pitch belt designed for light duty applications such as cooking, blanching and pasteurizing in the Food Industry.

Product features:

• Comes with various openings including fine-mesh for water drainage and filtering
• Steel reinforcement feature limits belt elongation (even in hot water)
• Reinforced product supports for high load elevators

uni SSB

Developed for heavy duty applications such as accumulation tables and packaging application.

Product features:

• Strong and wear-resistant belt
• Closed and wide hinge design increasing product stability
• Chamfered edges allowing stability in side transfer applications

uni ACB

The next level in automotive belting – the Advanced Concept Belt.

Versatile 40mm pitch belt used for medium duty vehicle and people conveying solutions.

Product features:

• High load capacity
• Lower construction heights (less pit depth)
• Patented dual compound technology
• Increased wear-resistance

uni OPB

Early generation 50mm pitch belt, available in a variety of executions.

Designed for high performance with various food products, especially for cooking, blanching and pasteurizing.

Executions and product features:

• Small or large opening including fine mesh for water drainage
• Finger plates for easy product transfer
• Pitch control with steel reinforcement feature

uni L-SNB

Easy clean, very open 2 inch pitch belt for various industries.

Product features:

• Less friction and product contact
• Large open area for easy drainage
• Small back flex radius for lower profile conveyors

uni MPB

The most cleanable straight running 2 inch pitch belt in the world!

Cleanable versatile 2 inch pitch belt series for a variety of applications mainly in the Food Industry.

Product features:

• Single Link^® feature reduces bacteria growth and prevents knive tips from getting stuck when using for cutting
• Holds valid NSF/USDA approvals
• Styles: closed or open surfaces; roller or rubber top
• Strong and thick product supports heavy loads without breakage
• Extensive range of flights available

uni UCB

The best performing Plastic Modular Belt on hygiene and cleanability in the industry.

Product features:

• Clean ability = Clean Belt
• Hybrid hinges
• Superior Hygienic Performance
• Lightweight
• Unique lock-pin system
• Hinge driven
• UltraClean Two-Part sprocket compatible
• Low cost of ownership

uni BLB

Open 2 inch pitch belt specifically designed for cooking, steaming and blanching vegetables.

A unique combination of materials prevent belt elongation and strength reduction even in high temperatures / boiling water.

Product features:

• Ideal for handling all sorts of sensitive food products
• Long life and low maintenance costs
• No marking on the products from belt surface
• Equally spread open area; open around the hinge
• Steel core does not come in contact with conveyed product

uni CSB

State-of-the-art, very strong and versatile 2 inch pitch belt.

Specially designed for the automotive, ’heavy load’ conveying and people moving industries.

Product features:

• High load capacity
• Dual compound technology allows for a combination of different materials within one conveyor belt
• Low construction height = less pit depth required

uni RTB

Versatile 2 inch pitch Roller Top Belt available with a variety of roller top surfaces.

Flexible and reliable handling solution for conveying products.

Product features:

• Numerous options for roller positioning
• Pinless Snap Link^® design enables easy assembling
• High efficiency with elimination of line stoppages and product damage

uni CPB

Strong 2 inch pitch belt used in medium / heavy duty conveying in a variety of different industries.

Can replace steel slat top chains and other technologies being used for high wear or heavy duty applications.

Product features:

• Long life and low maintenance costs
• Available in different surface options (e.g.: open for drainage and rough top surface for reduced slippage)
• Standard available in UV protected materials to be used in outdoor applications
• Easy to use lockpins

uni AMB

Our strongest (180,000 N/m) belt ever! The ultimate solution for higher loads. uni AMB benefits from the same unique and patented design principles and insert technology as our successful uni ACB and uni CSB...

Product features:

• Allows higher loads and longer conveyor lengths
• Larger wear zone provides longer lifetime
• Insert technology for wear resistant and EC inserts
• Ergonomic “low profile” grip surface
• Easy to clean
• Better sprocket engagement and less wear
• Execution in various materials
• Flame retardant (DIN 4102-B1), acid or heat resistant

uni X-MPB

Cleanable, strong 2.5 inch pitch belt equivalent of our MPB series. For applications where standard 2 inch pitch belting turns out to be too light.

Product features:

• Impact-resistance to withstand heavy objects falling onto the belt
• Strong and thick product supports allowing more load
• Unique lockpin locking system providing faster and simpler maintenance

uni XLB

The strongest belt in the “uni-verse”.

Early generation 2.5 inch pitch belt designed for heavy duty conveyors. The perfect belt to replace steel slat top chains, drag chains and other technologies used for high wear or heavy duty applications.

Product features:

• Extreme wear and impact-resistance
• Closed top and rough top
• V-shape for corrugated roll handling
